Datasheet 　　User Manual



geni box

Vertical Video Splitter



   Datasheet

   Large Image





















 Application:









Feature :



  • DP 1.4 Input  HDMI 1.3 x3  Output without Audio
  • Input Display Resolution:1920x3240@40Hz
  • Output Display Resolution: 1920x1080@60Hz x3 (1920x3240@60Hz)
  • Easy & Quick Install without Driver
  • Support Landscape & Portrait Mode by GPU Driver
  • Dimension WxHxD 110x35x144mm
  • Power Supply:  DC Jack +5V 6W
  • Model: PCV-DPHMV3-T23V4




System
 • Input DP 1.2  1920x3240@40Hz
 • Outpout HDMI 1.3 1920x1080@60Hz x3 (No-Audio)
 • Power Supply DC Jack +5V
 • Model PCV-DPHMV3-T23V4









 Structure and Operating Environment
 • Deminsion( H x W x D ) 110x35x144mm
 • Warranty 1 year
